ELMS PLUS 9mm Setup & Technical Instructions

For product setup, troubleshooting, and manufacturer technical support.

NOTE: For order-related issues such as returns or replacements, please use Amazon’s Buyer-Seller Messaging system inside your order details.

IMPORTANT SAFETY NOTICE

Do not install or use this product unless you are familiar with firearm safety and operation.

Before installing or using this product:

• Confirm all firearms are unloaded.
• Remove all live ammunition from the training area or room.
• Check that all magazines are empty.
• Always point in a safe direction during dry fire practice.

Improper or careless handling of firearms may result in injury, death, or property damage.

WHAT’S INCLUDED

• ELMS PLUS 9mm Laser Cartridge with reinforced back cap
• Extra O-rings
• 5 additional replaceable strike pads
• Instruction manual
• Carry case

1 set of batteries preloaded into the product.

STEP-BY-STEP SETUP

STEP 1 — Safety Confirmation

• Ensure all firearms are unloaded.
• Confirm no live ammunition is present in the training area or room.

STEP 2 — Battery Check

• Unscrew the back cap from the cartridge body.
• Remove the black battery protector tab if present.
• Ensure batteries are inserted with the unmarked (negative) side facing up.
• Screw the back cap onto the cartridge body until finger tight.

To test function:

• Point in a safe direction.
• Press firmly on the rear rubber strike pad using the tip of a ballpoint pen.
• A visible beam should activate momentarily.

If no activation occurs, recheck battery orientation and ensure the cap is secure.

STEP 3 — Chamber Installation

• Confirm again that the firearm is unloaded.
• Insert the cartridge fully into the chamber.
• Carefully close the action onto the cartridge.
• Gently guide the slide or bolt forward. Do not allow it to slam shut.

The cartridge remains seated and will not auto-eject during use.

NORMAL OPERATION – 9mm

• Activation occurs when the firing pin strikes the rear rubber strike pad.
• In double action platforms, activation occurs with each full trigger press.
• In single action platforms, you must cycle the slide between trigger presses.
• The triple O-ring design ensures a snug, centered chamber fit.
• The reinforced back cap is designed to withstand repeated firing pin impacts.

If partial trigger presses do not activate the unit, full trigger travel is required.

TROUBLESHOOTING – 9mm

If the cartridge does not fit:

• Lightly oil the O-rings using standard gun oil.
• Clean the barrel and chamber.
• If necessary, remove one O-ring to reduce friction.

If activation is inconsistent:

• Ensure full trigger press.
• Confirm strike pad is not excessively worn.
• Replace the strike pad if heavy dimpling or wear is visible.

If the unit seems loose:

• Confirm correct 9mm model selection.
• Inspect O-rings for wear or damage.

MAINTENANCE

• Treat the cartridge as an electronic device. Avoid high humidity and water exposure.
• Remove batteries if not used for extended periods.
• Dispose of batteries properly.
• Lightly oil O-rings periodically for smooth chamber fit.
• Replace strike pads when worn to maintain consistent activation.

COMPATIBILITY

Not compatible with:

• Ruger SR series
• Walther CCP
• All Hi-Point firearms

May not be compatible with all third-party systems.

APP COMPATIBILITY

• Compatible with companion mobile app.
• Requires iOS 10.0 / Android 6.0 or newer.
• Contains optional in-app purchase features.

WARRANTY

Covered under 1-Year Limited Warranty or 1000 laser “shots”, whichever occurs first.

See full warranty terms for details.

CARTRIDGE REMOVAL

Before removing the cartridge:

• Ensure the firearm is unloaded.
• Always verify the firearm is unloaded before inserting any object into the barrel.
• Remove the magazine.
• Lock the slide or action open.
• Confirm again that no live ammunition is present in the training area.

To remove the cartridge:

• Insert a wooden pencil or similar non-metal, non-sharp object into the barrel from the muzzle end.
• Gently push straight back toward the chamber.
• The cartridge will slide rearward and can be removed by hand once it clears the chamber.

Do not use metal tools, sharp objects, or excessive force.

If resistance is felt:

• Confirm the action is fully open.
• Apply steady, even pressure.
• Do not hammer or strike the object.

The cartridge is designed to remain seated during use and will not auto-eject. Manual removal is normal.

ELMS PLUS .380 ACP Setup & Technical Instructions

For product setup, troubleshooting, and manufacturer technical support.

NOTE: For order-related issues such as returns or replacements, please use Amazon’s Buyer-Seller Messaging system inside your order details.

IMPORTANT SAFETY NOTICE

Do not install or use this product unless you are familiar with firearm safety and operation.

Before installing or using this product:

• Confirm all firearms are unloaded.
• Remove all live ammunition from the training area or room.
• Check that all magazines are empty.
• Always point in a safe direction during dry fire practice.

Improper or careless handling of firearms may result in injury, death, or property damage.

WHAT’S INCLUDED

• ELMS PLUS .380 ACP Laser Cartridge with reinforced back cap
• Extra O-rings
• 5 additional replaceable strike pads
• Instruction manual
• Carry case

1 set of batteries preloaded into the product.

STEP-BY-STEP SETUP

STEP 1 — Safety Confirmation

• Ensure all firearms are unloaded.
• Confirm no live ammunition is present in the training area or room.

STEP 2 — Battery Check

• Unscrew the back cap from the cartridge body.
• Remove the black battery protector tab if present.
• Ensure batteries are inserted with the unmarked (negative) side facing up.
• Screw the back cap onto the cartridge body until finger tight.

To test function:

• Point in a safe direction.
• Press firmly on the rear rubber strike pad using the tip of a ballpoint pen.
• A visible beam should activate momentarily.

If no activation occurs, recheck battery orientation and ensure the cap is secure.

STEP 3 — Chamber Installation

• Confirm again that the firearm is unloaded.
• Insert the cartridge fully into the chamber.
• Carefully close the action onto the cartridge.
• Gently guide the slide forward. Do not allow it to slam shut.

The cartridge remains seated and will not auto-eject during use.

NORMAL OPERATION – .380 ACP

• Activation occurs when the firing pin strikes the rear rubber strike pad.
• Many .380 platforms have shorter firing pin travel than 9mm platforms.
• A firm, complete trigger press is required for activation.
• In single action platforms, you must cycle the slide between trigger presses.
• The triple O-ring design ensures a snug chamber fit.
• The reinforced back cap is designed to withstand repeated firing pin impacts.

If activation does not occur with partial trigger movement, this is normal. Full trigger travel is required.

IMPORTANT COMPATIBILITY NOTICE – .380 ACP

• Not compatible with revolvers.
• Not compatible with Ruger SR series.
• Not compatible with Walther CCP.
• Not compatible with Hi-Point firearms.

Due to design differences, some .380 platforms may vary in firing pin energy. This is normal and platform-dependent.

TROUBLESHOOTING – .380 ACP

If the cartridge does not fit:

• Lightly oil the O-rings using standard gun oil.
• Clean the barrel and chamber thoroughly.
• If necessary, remove one O-ring to reduce friction.

If activation is inconsistent:

• Ensure full trigger press.
• Confirm the cartridge is fully seated.
• Confirm strike pad is not excessively worn.
• Replace the strike pad if heavy dimpling or wear is visible.

If no activation occurs:

• Recheck battery orientation.
• Confirm the back cap is finger tight.
• Some .380 models may require slightly firmer trigger press due to shorter firing pin travel.

If the unit seems loose:

• Inspect O-rings for wear or damage.

MAINTENANCE

• Treat the cartridge as an electronic device. Avoid high humidity and water exposure.
• Remove batteries if not used for extended periods.
• Dispose of batteries properly.
• Lightly oil O-rings periodically for smooth chamber fit.
• Replace strike pads when worn to maintain consistent activation.

APP COMPATIBILITY

• Compatible with companion mobile app.
• Requires iOS 10.0 / Android 6.0 or newer.
• Contains optional in-app purchase features.

WARRANTY

Covered under 1-Year Limited Warranty or 1000 laser “shots”, whichever occurs first.

See full warranty terms for details.

CARTRIDGE REMOVAL

Before removing the cartridge:

• Ensure the firearm is unloaded.
• Remove the magazine.
• Lock the slide or action open.
• Confirm again that no live ammunition is present in the training area.

Always verify the firearm is unloaded before inserting any object into the barrel.

To remove the cartridge:

• Insert a wooden pencil or similar non-metal, non-sharp object into the barrel from the muzzle end.
• Gently push straight back toward the chamber.
• The cartridge will slide rearward and can be removed by hand once it clears the chamber.

Do not use metal tools, sharp objects, or excessive force.

If resistance is felt:

• Confirm the action is fully open.
• Apply steady, even pressure.
• Do not hammer or strike the object.

Manual removal is normal.

ELMS PLUS .45 ACP   Setup & Technical Instructions

For product setup, troubleshooting, and manufacturer technical support.

NOTE: For order-related issues such as returns or replacements, please use Amazon’s Buyer-Seller Messaging system inside your order details.

IMPORTANT SAFETY NOTICE

Do not install or use this product unless you are familiar with firearm safety and operation.

Before installing or using this product:

• Confirm all firearms are unloaded.
• Remove all live ammunition from the training area or room.
• Check that all magazines are empty.
• Always point in a safe direction during dry fire practice.

Improper or careless handling of firearms may result in injury, death, or property damage.

WHAT’S INCLUDED

• ELMS PLUS .45 ACP Laser Cartridge with reinforced back cap
• Extra O-rings
• 5 additional replaceable strike pads
• Instruction manual
• Carry case

1 set of batteries preloaded into the product.

STEP-BY-STEP SETUP

STEP 1 — Safety Confirmation

• Ensure all firearms are unloaded.
• Confirm no live ammunition is present in the training area or room.

STEP 2 — Battery Check

• Unscrew the back cap from the cartridge body.
• Remove the black battery protector tab if present.
• Ensure batteries are inserted with the unmarked (negative) side facing up.
• Screw the back cap onto the cartridge body until finger tight.

To test function:

• Point in a safe direction.
• Press firmly on the rear rubber strike pad using the tip of a ballpoint pen.
• A visible beam should activate momentarily.

If no activation occurs, recheck battery orientation and ensure the cap is secure.

STEP 3 — Chamber Installation

• Confirm again that the firearm is unloaded.
• Insert the cartridge fully into the chamber.
• Carefully close the action onto the cartridge.
• Gently guide the slide or bolt forward. Do not allow it to slam shut.

The cartridge remains seated and will not auto-eject during use.

NORMAL OPERATION – .45 ACP

• Activation occurs when the firing pin strikes the rear rubber strike pad.
• In double action platforms, activation occurs with each full trigger press.
• In single action platforms, you must cycle the slide between trigger presses.
• The triple O-ring design ensures a snug, centered chamber fit.
• The reinforced back cap is designed to withstand repeated firing pin impacts.

If activation does not occur with partial trigger movement, full trigger travel is required.

TROUBLESHOOTING – .45 ACP

If the cartridge does not fit:

• Lightly oil the O-rings using standard gun oil.
• Clean the barrel and chamber thoroughly.
• If necessary, remove one O-ring to reduce friction.

If activation is inconsistent:

• Ensure full trigger press.
• Confirm the cartridge is fully seated.
• Confirm strike pad is not excessively worn.
• Replace the strike pad if heavy dimpling or wear is visible.

If no activation occurs:

• Recheck battery orientation.
• Confirm the back cap is finger tight.

If the unit seems loose:

• Inspect O-rings for wear or damage.

MAINTENANCE

• Treat the cartridge as an electronic device. Avoid high humidity and water exposure.
• Remove batteries if not used for extended periods.
• Dispose of batteries properly.
• Lightly oil O-rings periodically for smooth chamber fit.
• Replace strike pads when worn to maintain consistent activation.

COMPATIBILITY

Not compatible with:

• Ruger SR series
• Walther CCP
• All Hi-Point firearms

May not be compatible with all third-party systems.

APP COMPATIBILITY

• Compatible with companion mobile app.
• Requires iOS 10.0 / Android 6.0 or newer.
• Contains optional in-app purchase features.

WARRANTY

Covered under 1-Year Limited Warranty or 1000 laser “shots”, whichever occurs first.

See full warranty terms for details.

CARTRIDGE REMOVAL

Before removing the cartridge:

• Ensure the firearm is unloaded.
• Always verify the firearm is unloaded before inserting any object into the barrel.
• Remove the magazine.
• Lock the slide or action open.
• Confirm again that no live ammunition is present in the training area.

To remove the cartridge:

• Insert a wooden pencil or similar non-metal, non-sharp object into the barrel from the muzzle end.
• Gently push straight back toward the chamber.
• The cartridge will slide rearward and can be removed by hand once it clears the chamber.

Do not use metal tools, sharp objects, or excessive force.

If resistance is felt:

• Confirm the action is fully open.
• Apply steady, even pressure.
• Do not hammer or strike the object.

Manual removal is normal.

ELMS PLUS .40 S&W   Setup & Technical Instructions

For product setup, troubleshooting, and manufacturer technical support.

NOTE: For order-related issues such as returns or replacements, please use Amazon’s Buyer-Seller Messaging system inside your order details.

IMPORTANT SAFETY NOTICE

Do not install or use this product unless you are familiar with firearm safety and operation.

Before installing or using this product:

• Confirm all firearms are unloaded.
• Remove all live ammunition from the training area or room.
• Check that all magazines are empty.
• Always point in a safe direction during dry fire practice.

Improper or careless handling of firearms may result in injury, death, or property damage.

WHAT’S INCLUDED

• ELMS PLUS .40 S&W Laser Cartridge with reinforced back cap
• Extra O-rings
• 5 additional replaceable strike pads
• Instruction manual
• Carry case

1 set of batteries preloaded into the product.

STEP-BY-STEP SETUP

STEP 1 — Safety Confirmation

• Ensure all firearms are unloaded.
• Confirm no live ammunition is present in the training area or room.

STEP 2 — Battery Check

• Unscrew the back cap from the cartridge body.
• Remove the black battery protector tab if present.
• Ensure batteries are inserted with the unmarked (negative) side facing up.
• Screw the back cap onto the cartridge body until finger tight.

To test function:

• Point in a safe direction.
• Press firmly on the rear rubber strike pad using the tip of a ballpoint pen.
• A visible beam should activate momentarily.

If no activation occurs, recheck battery orientation and ensure the cap is secure.

STEP 3 — Chamber Installation

• Confirm again that the firearm is unloaded.
• Insert the cartridge fully into the chamber.
• Carefully close the action onto the cartridge.
• Gently guide the slide or bolt forward. Do not allow it to slam shut.

The cartridge remains seated and will not auto-eject during use.

NORMAL OPERATION – .40 S&W

• Activation occurs when the firing pin strikes the rear rubber strike pad.
• In double action platforms, activation occurs with each full trigger press.
• In single action platforms, you must cycle the slide between trigger presses.
• The triple O-ring design ensures a snug, centered chamber fit.
• The reinforced back cap is designed to withstand repeated firing pin impacts.

If activation does not occur with partial trigger movement, full trigger travel is required.

IMPORTANT COMPATIBILITY NOTICE – .40 S&W

• Not compatible with Ruger SR series.
• Not compatible with Walther CCP.
• Not compatible with Hi-Point firearms.

TROUBLESHOOTING – .40 S&W

If the cartridge does not fit:

• Lightly oil the O-rings using standard gun oil.
• Clean the barrel and chamber thoroughly.
• If necessary, remove one O-ring to reduce friction.

If activation is inconsistent:

• Ensure full trigger press.
• Confirm the cartridge is fully seated.
• Confirm strike pad is not excessively worn.
• Replace the strike pad if heavy dimpling or wear is visible.

If no activation occurs:

• Recheck battery orientation.
• Confirm the back cap is finger tight.

If the unit seems loose:

• Inspect O-rings for wear or damage.

MAINTENANCE

• Treat the cartridge as an electronic device. Avoid high humidity and water exposure.
• Remove batteries if not used for extended periods.
• Dispose of batteries properly.
• Lightly oil O-rings periodically for smooth chamber fit.
• Replace strike pads when worn to maintain consistent activation.

APP COMPATIBILITY

• Compatible with companion mobile app.
• Requires iOS 10.0 / Android 6.0 or newer.
• Contains optional in-app purchase features.

WARRANTY

Covered under 1-Year Limited Warranty or 1000 laser “shots”, whichever occurs first.

See full warranty terms for details.

CARTRIDGE REMOVAL

Before removing the cartridge:

• Ensure the firearm is unloaded.
• Always verify the firearm is unloaded before inserting any object into the barrel.
• Remove the magazine.
• Lock the slide or action open.
• Confirm again that no live ammunition is present in the training area.

To remove the cartridge:

• Insert a wooden pencil or similar non-metal, non-sharp object into the barrel from the muzzle end.
• Gently push straight back toward the chamber.
• The cartridge will slide rearward and can be removed by hand once it clears the chamber.

Do not use metal tools, sharp objects, or excessive force.

If resistance is felt:

• Confirm the action is fully open.
• Apply steady, even pressure.
• Do not hammer or strike the object.

Manual removal is normal.

ELMS PLUS 10mm Setup & Technical Instructions

For product setup, troubleshooting, and manufacturer technical support.

NOTE: For order-related issues such as returns or replacements, please use Amazon’s Buyer-Seller Messaging system inside your order details.

IMPORTANT SAFETY NOTICE

Do not install or use this product unless you are familiar with firearm safety and operation.

Before installing or using this product:

• Confirm all firearms are unloaded.
• Remove all live ammunition from the training area or room.
• Check that all magazines are empty.
• Always point in a safe direction during dry fire practice.

Improper or careless handling of firearms may result in injury, death, or property damage.

WHAT’S INCLUDED

• ELMS PLUS 10mm Laser Cartridge with reinforced back cap
• Extra O-rings
• 5 additional replaceable strike pads
• Instruction manual
• Carry case

1 set of batteries preloaded into the product.

STEP-BY-STEP SETUP

STEP 1 — Safety Confirmation

• Ensure all firearms are unloaded.
• Confirm no live ammunition is present in the training area or room.

STEP 2 — Battery Check

• Unscrew the back cap from the cartridge body.
• Remove the black battery protector tab if present.
• Ensure batteries are inserted with the unmarked (negative) side facing up.
• Screw the back cap onto the cartridge body until finger tight.

To test function:

• Point in a safe direction.
• Press firmly on the rear rubber strike pad using the tip of a ballpoint pen.
• A visible beam should activate momentarily.

If no activation occurs, recheck battery orientation and ensure the cap is secure.

STEP 3 — Chamber Installation

• Confirm again that the firearm is unloaded.
• Insert the cartridge fully into the chamber.
• Carefully close the action onto the cartridge.
• Due to heavier recoil springs common in 10mm platforms, guide the slide forward with steady pressure. Do not allow it to slam shut.

The cartridge remains seated and will not auto-eject during use.

NORMAL OPERATION – 10mm

• Activation occurs when the firing pin strikes the rear rubber strike pad.
• 10mm platforms typically have strong striker or firing pin energy.
• In double action platforms, activation occurs with each full trigger press.
• In single action platforms, you must cycle the slide between trigger presses.
• The triple O-ring design ensures a snug, centered chamber fit.
• The reinforced back cap is designed to withstand repeated firing pin impacts.

If activation does not occur with partial trigger movement, full trigger travel is required.

TROUBLESHOOTING – 10mm

If the cartridge does not fit:

• Lightly oil the O-rings using standard gun oil.
• Clean the barrel and chamber thoroughly.
• If necessary, remove one O-ring to reduce friction.

If activation is inconsistent:

• Ensure full trigger press.
• Confirm the cartridge is fully seated.
• Confirm strike pad is not excessively worn.
• Replace the strike pad if heavy dimpling or wear is visible.

If no activation occurs:

• Recheck battery orientation.
• Confirm the back cap is finger tight.
• Ensure the slide is fully in battery before testing.

If the unit seems loose:

• Inspect O-rings for wear or damage.

MAINTENANCE

• Treat the cartridge as an electronic device. Avoid high humidity and water exposure.
• Remove batteries if not used for extended periods.
• Dispose of batteries properly.
• Lightly oil O-rings periodically for smooth chamber fit.
• Replace strike pads when worn to maintain consistent activation.

COMPATIBILITY

Not compatible with:

• Ruger SR series
• Walther CCP
• All Hi-Point firearms

May not be compatible with all third-party systems.

APP COMPATIBILITY

• Compatible with companion mobile app.
• Requires iOS 10.0 / Android 6.0 or newer.
• Contains optional in-app purchase features.

WARRANTY

Covered under 1-Year Limited Warranty or 1000 laser “shots”, whichever occurs first.

See full warranty terms for details.

CARTRIDGE REMOVAL

Before removing the cartridge:

• Ensure the firearm is unloaded.
• Always verify the firearm is unloaded before inserting any object into the barrel.
• Remove the magazine.
• Lock the slide or action open.
• Confirm again that no live ammunition is present in the training area.

To remove the cartridge:

• Insert a wooden pencil or similar non-metal, non-sharp object into the barrel from the muzzle end.
• Gently push straight back toward the chamber.
• The cartridge will slide rearward and can be removed by hand once it clears the chamber.

Do not use metal tools, sharp objects, or excessive force.

If resistance is felt:

• Confirm the action is fully open.
• Apply steady, even pressure.
• Do not hammer or strike the object.

Manual removal is normal.
